Multi-function Measurement Instrument

The PMM-2 is an ideal instrument for use in general electrical systems maintenance, electrical machine repairs, protective relay testing or in monitoring power at the electrical service entrance. Motor starting currents, voltages, and power can be captured for analysis.

The PMM-2 is designed to perform fast, accurate checking and testing of protective relay and meter installations during their commissioning and in routine maintenance.

For meter installations, unit can be configured to measure phase-to-phase voltage and single-phase current amplitudes and phase angles. Combined with a voltage or current source, the PMM-2 also becomes an excellent tool for testing and calibrating virtually any type of protective relay.

• Integrated onboard LCD touch-screen display
• Multi-coloured graphics with intuitive navigation
• Built-in report generator, timer, and event logging
• High-speed sampling and data recording
• Measure and display up to four voltages and four currents simultaneously
• Accurate phase angle measurements at low current levels
• Low-level AC/DC inputs available
• Portable battery-operated instrument
• Standard case and a rugged model

PMM-2 Details

Measurement System

The ICMsystem is a powerful, versatile instrument for evaluating the condition of medium and high voltage insulation.

The ICMsystem is part of the Power Diagnostix ICMseries of digital partial discharge detectors. It is usable over a range of frequencies of applied voltage, including power system frequency (50/60 Hz) and VLF (0.1 Hz).

Partial discharge (PD) measurements are a proven method for effective, nondestructive evaluation of electrical insulation. The Power Diagnostix ICMsystem provides high-resolution digital PD patterns for classification of defects in high voltage insulation systems.

ICMsystem datasheet

Lamp Adaptor Kit

The Megger LA-KIT provides the user with 5 separate lamp socket adaptors, to allow electrical test equipment to be connected to the circuit via industry standard 4 mm sockets, for measurement and test purposes, without the need to disturb the circuit wiring or lamp housing. Includes B22 Lamp Adaptor, B14 Lamp adaptor, E27 Lamp adaptor, E14 Lamp adaptor, GU10 Lamp adaptor, 2 Wire lead set, Protective carry case.

• 5 most common lamp adaptors
• Allows easy testing at the lamp sockets
• IEC61010 compliant
• Supplied with 2-wire lead set
•  Carry case included

LA-KIT Datasheet

Socket Adaptor

The Megger MSA1363 and MTF230 Socket Adaptors enable connection of electrical test instruments to the line, neutral and earth of a circuit via a standard socket outlet, removing the need to dismantle the socket or expose any live terminals or connections. Colour coded front mounted sockets enable test leads or equipment to be connected quickly, accurately and safely. Using the adapter saves potential damage to the socket or surrounding decoration and allows measurements to be taken using instrument leads that use standard 4 mm connectors.

• R1 and R2 testing
• Colour coded terminals
• Standard 4 mm terminals
• CAT II 300 V
• Safe and simple to use

MSA1363 and MTF230 Datasheet

Audible Socket Tester

The Megger MST220 Socket Tester is a plug-in style tester that uses both a visual and audible indication to provide quick and easy indication of possible wiring errors which may be present at UK BS1363 13 A 3-pin power sockets. Over 17 combinations of wiring fault can be identified including missing wires and incorrect or reversed connections.

• Simple and effective identification of faulty wiring at sockets
• Tri-coloured LEDs for instant error reporting and fault diagnosis
• Audible indication of correct and incorrect connections
• Identifies 17 missing wire and wrong connection combinations
• Easy to use
• Rugged and reliable

Megger MST220 Datasheet

Stud Locator

The Megger MSL10 is a simple to use instrument, designed to help locate the edges of wooden studs, metal joists or live AC cables through drywall or other common building materials. With clear LED and audible indication, the centre of studs or joists can be located by scanning from either side to locate each edge.

• Locate wooden joists or studs
• Locate metal joists or studs
• Locate live AC cables
• Simple to use
• Adjustable depth range
• Audible and visual indication
• Carry case included

Megger MFL10 Datasheet
