Designed for Enterprise, Datacenter, Outside Plant, and PON Fiber

Many OTDRs designed for fiber troubleshooting are designed for carrier and contain cumbersome and complicated features. The OptiFiber Pro OTDR family is the first class of OTDRs that is built with features and usability for both the enterprise network engineers, and cable installers working in both enterprise and OSP environments.

Product Highlights

Makes novices into experts and experts faster

• Multiple wavelengths (850, 1300, 1310,1490, 1550 and 1625 nm) support LAN, datacenters, PON, FTTx and outside plant applications.
• Automated setup senses fiber characteristics and sets measurement parameters
• Manual Expert mode allows simple adjustments to automated settings for detailed testing.
• EventMap automatically identifies events including connectors, splices, bends, and splitters
• Gesture-based interface allows fast, in-depth trace analysis
• SmartLoop™ OTDR technology tests two fibers in a single test eliminating the need to travel to the far end of the connection to perform tests.
• Instantaneous on-board bi-directional averaging results included as standard
• Integrates with LinkWare™ Live to manage jobs and testers from any smart device.
• Future-ready VersivTM design supports copper certification to Category 8, fiber loss and inspection.

OptiFiber® Pro OTDR Family Datasheet

Handheld portable appliance testers

The PAT100 series of hand-held portable appliance testers enable simple, fast safety testing in all environments including offices, shops and business units. It is ideally suited to training organisations, easy to learn to use, tough and reliable yet with full functionality.

• Simple tick or cross, pass or fail indication plus measurement
• Tough, rubber armoured with built-in front cover, hardened, scratch-proof display window
• Includes 250 V insulation and leakage testing for safe IT testing and surge protected devices
• Testing portable and fixed electrical equipment
• 10 mA and 30 mA portable RCD lead testing (PAT150)
• Adjustable PASS test limits (PAT150)
• Substitute and mains powered leakage testing (PAT150)
• Battery powered with rechargeable options

There are 3 testers in the range:

PAT120 simple PAT tester offer Class I, Class II and power and extension lead testing with fixed pass limits; because it has two insulation test voltages it can be used to test IT and surge protected equipment.

PAT150 full functionality PAT tester adds to the offering Portable RCD (PRCDs) testing at 10 mA and 30 mA, separate tests for continuity, insulation, mains powered leakage testing and SELV measurements using the quick test (QT) button, and can be used for testing fixed appliances.

PAT150R is a rechargeable version of the PAT150.

PAT100 series datasheet

The Utility Solutions Rescue Hooks are used to remove an injured worker from hazardous locations, including confined spaces, electrical gear and vaults.

The standard model Rescue Hook is made of high performance, 1.25” diameter closed cell foam filled fiberglass and includes a heavy duty rubber boot. The telescopic model has an internal 1.25” diameter closed cell foam filled fiberglass section which collapses into a 1.75” diameter outer section. Two machined buttons secure the Rescue Hook in the open position.

Both models use a 20” wide tempered steel hook that is powder-coated in high visibility yellow. The innovative design allows the hook to separate for freight savings and ease of use via the included Allen wrench and fasteners.

All BLUE STRIPE® Fiberglass Sticks are manufactured to meet industry standards including OSHA, ASTM and IEC as applicable

Rescue Hook Datsheet

GridGis Connect

In order to manage efficiently the distribution network it is essential to have a precise and up-to-date knowledge of the topology data of the Low Voltage grid.

GridGIS Connect app enables field personnel to work with the ILF G2 | ILF G2 Pro, phase and feeder identifiers, and store automatically identification results of electric meter electric connection upstream with Secondary Substation (SS), feeder and phase (electric meter topology).

Suitable for different distribution network arrangements, wether in parallel or cascade mode on wich user can determine the topology data of the consumer with respect to all its distribution elements upstream (Feeder Pillars, or similar) of the LV network, in one only measurement.

Through this application captured data is displayed, on a map view of the work area. After completing work, the results are exportable to the Utility GIS system in a quick and easy way.

GridGIS Map Creator

GridGIS Map Creator app allows to map, with GPS coordinates, aerial/underground MV and LV electrical networks with different assets directly on the field. Design to work with the MRT-700, underground cable locator de Merytronic.

GridGIS Applications Datasheet

Thermal imaging locates hot spots by examining the IR spectrum.
Excessive current or high impedance will elevate heat in a system.
As current flows through a system, it will produce energy in the form of heat or IR radiation.

Application Note:
Thermal Imaging & the Heating Effects Related to Power Quality

Megger TC3231

Fluke Corporation is the world leader in compact and professional electronic test tools.
From industrial maintenance to commercial building operations, Fluke tools deliver the testing and troubleshooting capabilities to keep the world up and running.

Fluke Test Tool Catalogue 2022
