Cable testing you trust.  Network testing you need.

The LinkIQ™ Network+Cable Tester is designed to provide trusted cable testing along with network testing professionals need to do their jobs. LinkIQ™ validates cable performance (up to 10 Gig) using frequency-based measurements and provides distance to fault information along with a wire map of the cable under test. The LinkIQ™ also performs nearest switch diagnostics to identify key network issues and validate switch configuration eliminating the need of using another device. Additional features include Analog and Digital Toning, Port Blink, 802.1x authentication, Remote Office Locators, and the ability to manage results via LinkWare™ PC.

Product Highlights

• Measure network capacity up to 10 Gig via frequency-based measurements
• Troubleshoot active networks by providing connected switch information (Switch Name, Port Number, and VLAN info)
• Install and troubleshoot PoE devices via Switch Negotiation and PoE Load test
• Graphical wiremap and length test to identify common faults that occur with cabling installation
• Document work through LinkWare™ PC reporting
• Support all Industrial Ethernet Protocols (EtherNet/IP, PROFINET, EtherCAT, and others)
• Industrial Ethernet Kit supports Industrial Connectors (M8D, M12D, M12X)

LinkIQ™ Cable + Network Tester Details

MEGGER TDM 45 High Power Test & Diagnostics Combination For Medium Voltage Cables

• Cable testing, cable diagnosis and sheath testing in one device
• Allows standard high power VLF testing at 0.1 Hz (5 μF @ 40 kVrms)
• Internal tanDelta measurements with automatic result interpretation
• Diagnosis of partial discharge using the VLF Sine wave method, AC Damped or 50/60 Hz Slope

The Megger TDM 45 represents Megger's revolutionary breakthrough in testing and diagnosis of medium voltage (MV) cables. This patented concept is very helpful in today's utility concepts which increasingly require flexibility in the use of test and measurement equipment based on the type of application required.

Megger TDM 45 has a modular concept that allows engineers or operators in the field to arrange units based on the type of work that needs to be executed. For example, when doing a withstand testing on a cable that is not too long, only one module is needed for the test. Meanwhile, when a partial discharge diagnostic test is needed, an additional module is needed to carry out this test.

The Fluke ii910 is the perfect tool for high-voltage electricians, electrical testing technicians, and grid maintenance teams who constantly check and maintain power distribution and industrial high-voltage equipment. The Fluke ii910 provides a safe and fast way to detect and locate partial discharge to maintain high-voltage equipment and prevent catastrophic events. With a 7 inch 1280 x 800 LCD screen, touch screen, and SoundSight ™ technology. The Fluke ii910 translates the sound it hears into a visual representation so you can quickly find problem areas. The ii910's higher frequency capability enables early detection to facilitate advance maintenance planning, which is why the ii910 has a frequency range of 2-100 kHz with a detection range capability of up to 120 meters

Fluke ii910 Precision Acoustic Imager

Online Handheld Partial Discharge Scanner

• To quickly verify partial discharge activity in medium voltage (MV) and high voltage (HV) systems
• Universal application range, thanks to a wide range of sensors
• For a quick assessment of the condition of switchgear, cables, and other electrical equipment
• Determine the point or source of the problem for maintenance information purposes
• Improve work safety in factories or electrical systems because potential risks can be detected early
• Complete documentation thanks to an integrated digital camera, QR code scanner, temperature and humidity
• Equipped with comfortable Bluetooth® Headphones Automatic evaluation and interpretation of results
• Can also use a mobile device for wireless data transfer

Megger PD Scan

The NEW Megger TTRU3 transformer turns ratiometer uses revolutionary design to perform a complete series of measurements on a transformer, including 3Ø step-up turns ratio testing (patent pending).

TTRU3

40kV High-End Portable Cable fault location system
